Xray In Chrome

XrayInChrome is a powerful tool that integrates Xray core control directly into the browser's side panel. By leveraging the Chrome Native Messaging mechanism, it achieves a seamless connection between the browser UI and system-level network processes, allowing users to manage network proxies efficiently without dealing with complex command lines or tedious configuration files.

Core Features

🚀 Minimalist Control Center: Real-time control of Xray core startup, shutdown, and status monitoring via the Chrome Side Panel.
📦 Intelligent Subscription Management: Support for one-click import of node links, automatically parsing and syncing them to local state.
📜 Real-time Log Stream: View Xray runtime logs directly in the browser interface for rapid connection troubleshooting.
⚙️ Automated Deployment: Built-in Go-based Native Host with one-click registry installation.
🛡️ Privilege Separation Architecture: Employs a low-privilege frontend + high-privilege backend architecture for enhanced security.

Setup Guide

Step 1: Get and Start Setup

Visit the GitHub Repository to download and run the setup guide xray-bridge.exe.

Step 2: Confirm Intent

Select 'Yes' in the popup dialog to start installing or updating the bridge.

Step 3: Link Core

Select the xray.exe core file on your computer and click OK. This registers the bridge in the Windows Registry, granting Chrome permission to call Xray.

Step 4: Load Extension

1. Open Chrome and navigate to chrome://extensions/
2. Enable Developer mode (top right toggle)
3. Click Load unpacked
4. Select the extension folder in the project directory

Step 5: Verify Connection

Restart your browser and click the 'Xray in Chrome' extension button to open the side panel. The bridge will start automatically; confirm that xray-bridge.exe status becomes 'Running'.

Step 6: Configure Nodes

Import proxy nodes in the 'Server' page and click to select a target node (marked with ✅) as the active configuration.

Step 7: Start Core

Enable the toggle in the top right of the 'Home' page. Once the status is 'Running' and logs are clear, the Xray core is started successfully.

Step 8: Route Traffic

In the 'Others' (System Settings) page, check 'Use Xray Proxy' and click 'Apply'. Browser traffic will now be forwarded via Xray.

System Architecture

XrayInChrome adopts a Privilege Separation architecture to ensure both operational convenience and system security:

[ Chrome Browser ]
       │
       ▼
[ Sidepanel UI ]  <───>  [ Background Script ]
                                 │
                                 │ (Chrome Native Messaging API)
                                 ▼
                         [ Go Native Host ]  <───>  [ Windows Registry ]
                                 │
                                 │ (Process Management)
                                 ▼
                         [ Xray Core Process ]  <───>  [ Network Traffic ]

Frontend (Extension): Responsible for UI interaction, subscription parsing, and configuration orchestration.
Native Host (Go): Responsible for Xray process lifecycle management, physical generation of config files, and system calls.
Xray Core: The actual binary executing the network proxy logic.

Security Note

This project operates via Chrome's officially supported Native Messaging mechanism:

Controlled Communication: The extension cannot arbitrarily access your file system; all system operations must pass strict validation by the native-host.
Explicit Authorization: Installing the backend requires administrator privileges (modifying the registry), ensuring that installation is a user-perceived and authorized action.
Least Privilege: The extension only requests necessary API permissions and does not run any third-party remote scripts.

Disclaimer:

Compliance: The user is solely responsible for ensuring that the use of this project and its derivatives complies with all applicable local laws and regulations.
Assumption of Liability: Any and all legal liabilities, disputes, or consequences arising from the use of this project and its derivatives shall be borne exclusively by the user.
